Aprašymas

"Supermicro MBD-X14SAE-005. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 192 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet. Component for: Server, Motherboard form factor: ATX, Motherboard chipset family: Intel"\n"Intel Core Ultra 9/7/5 Series Processor, Single Socket LGA-1851(Intel® V1 Socket) supported, CPU TDP supports Up to 125W TDP Up to 192GB Unbuffered ECC/non-ECC UDIMM, DDR5-5600MHz, in 4 DIMM slots M.2 Interface: 1 PCIe 4.0 x4 and 1 PCIe 5.0x4 (support M.2 Form Factor 2280 only) M.2 Form Factor: 2280/22110 M.2 Key: M-Key 2 M.2 slots (1 PCIe 4.0 x4 from PCH; support 2280/22110, and 1 PCIe5.0 x4 from CPU, support 2280) 2 PCIe 5.0 x16 slots, 1 PCIe 4.0 x4 slot A 2.5 Gigabit LAN with Intel® Ethernet i226LM LAN controller A 1 Gigabit LAN with Intel® Ethernet i219LM LAN controller [AMT/vPro] 1 HDMI 2.1*, 1 DP 2.1**, 1 Thunderbolt™ 4.0 Type-C® *Supports data rates of up to 10 Gbps **Supports data rates of up to 10 Gbps Intel® W880 Controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10 Supports Thunderbolt 4 Onboard TPM2.0

"
