| RAM |
128 MB |
| Flash Memory |
32 MB |
| Buffer Memory |
512 KB |
| Number of Ports |
8 x 10Base-T/100Base-TX/1000Base-T (Gigabit Ethernet/Fast Ethernet/Ethernet) |
| Switching Method |
Store and Forward |
| Switching Layers |
Layer 2
Layer 3
Layer 4 |
| MAC Address Table Size |
8K |
| Network/Transport Protocol |
IPv4
TCP/IP
UDP
HTTP
IPv6
TFTP
DNS
UPnP
HTTPS
QoS
IGMP
SNMP
IGMPv2
MLDv1
RMON
IGMPv3
MLDv2
SIP
LLDP |
| Status LED Indicators |
Activity Status, Link, Speed |
| Data Transmission |
Full Duplex |
| Networking Compliant Standards |
IEEE 802.1D(Spanning Tree Protocol)
IEEE 802.1p(QoS)
IEEE 802.1Q(VLAN)
IEEE 802.1X
IEEE 802.3ad
IEEE 802.1w
IEEE 802.1ab
IEEE 802.3az
IEEE 802.1s |
| Networking Features |
DHCP Client Built-in
Jumbo Frames Support
DoS Attack Protection
Radius/TACACS+ |
| Device Location |
External |
| Mounting Capability |
Desktop/Wallmount |
| LAN |
8 (RJ-45) |
| Power Consumption Operational |
5.5 W |
| Power Consumption Stand By/Sleep |
1.9 W |
| Depth (mm) |
101 mm |
| Height (mm) |
27 mm |
| Width (mm) |
158 mm |
| Nominal Weight |
0.43 kg |
| External Color |
Gray |
| Maximum Operating Ambient Temperature |
40 °C |
| Maximum Operating Humidity |
95 % |
| Minimum Operating Ambient Temperature |
0 °C |
| Mean Time Between Failures |
2388657 hr |
| Warranty Products returnable |
Yes |
| Warranty Term (month) |
60 month(s) |
| Warranty validation Criteria |
Serial Number |
| Pack Length (mm) |
101 mm |
| Pack Width (mm) |
158 mm |
| Pack Height (mm) |
27 mm |
| Pack Weight Brutto (kg) |
0.7 kg |
| Pack Weight Netto (kg) |
0.43 kg |
| Pieces in pack |
1 |
| Box Weight Brutto (kg) |
0.7 kg |
| Retail Packaging Net Weight Carton |
0.1 kg |
| Retail Packaging Net Weight Plastic |
0.05 kg |
| Packs in Box |
1 |
| Package Type |
Box |
