Aprašymas

"METZ CONNECT RJ45. Connector(s): RJ45, Product colour: Metallic, Material: Nickel, Zinc. Compliance certificates: RoHS. Width: 12.9 mm, Depth: 40.2 mm, Height: 9.45 mm. Package length: 5.8 cm, Package width: 247 mm, Package height: 161 mm"\n"- Cat.6 class EA plug to be assembled in the field and mounted in IP67 plug housings of variants 1, 4, 5 and 14.
- Compliance with class EA to ISO/IEC 11801 Ed.2.2:2011-06, DIN EN 50173-1:2011-09.
- 10 GBit suitable according to IEEE 802.3an.
- Suitable for Power over Ethernet (PoE, PoE plus and UPoE).
- 8-wire RJ45 plug for AWG 22 to be assembled in the field.
- Connection of AWG 26/7 - 22/7; AWG 26/1 - 22/1 possible.
- Solid copper wire diameter from 0.4 to 0.64 mm.
- Stranded copper wire diameter from 0.48 to 0.76 mm.
- Conductor diameter up to 1.6 mm.
- Cable jacket from 5.5 to 8.5 mm.
- Consists of only 2 parts.
- Easy assembly - connection without special tools.
- Zinc die-cast housing for industrial use.
- Protected locking hook.
- Can be used as test plug at IP67 end of variants 1, 4, 5, 6 and 14.
- Variants: T568A, T568B, Industry."
