Maršrutizatorius (Router)
Mikrotik Wired Ethernet Router RB1100AHx4 Dude Edition, 1U Rackmount, Quad core 1.4GHz CPU, 1 GB RAM, 128 MB, 60GB M.2 SSD included, 13xGigabit LAN, 1xSerial console port RS232, 2x SATA3 ports, 2xM.2 slots, PCB Temperature and Voltage Monitor (CAPsMAN, Monitor Devices, Shows Historical Data, Can Write Messeges), IP20, RouterOS L6 | Wired Ethernet Router | RB1100AHx4 Dude Edition | No Wi-Fi | Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 13 | Mesh Support No | MU-MiMO No | No mobile broadband | Antenna type | 12 month(s)
Prekė gali skirtis nuo pavaizduotos paveikslėlyje, taip pat paveikslėlyje gali būti dalių, kurių nėra prekės komplektacijoje.
Prekės kodas: #16777
Garantija: 12 mėn.
-
Informacija apie prekę
-
Papildoma informacija
Gamintojas |
MIKROTIK |
Montavimas |
Montuojami (rack-mountable) |
Garantija |
12 |
Bruto svoris |
2.12 |
Neto svoris |
1.80 |
Dydžio formatas |
Rack mountable |
Perjungimo tipas |
Web Management |
Gigabit Ethernet (varinių) prievadų kiekis |
13 |
Maitinimo tipas |
Dual Redundant |
Vidinė atmintis |
1 |
Gamintojo prekės modelio pavadinimas |
RB1100AHx4 Dude Edition |
Predominant port type |
1 Gbps (RJ-45) |
Programinės įrangos tipas |
RouterOS (level 6) |
Atmintukas |
128 MB + M.2 SSD 60 |
"Ethernet" vietinio tinklo duomenų perdavimo greitis |
10/100/1000 |
Ethernet LAN (RJ-45) prievadai |
13 |
RS-232 prievadai |
1 |
I/O prievadai |
2x M.2, 2x SATA3 |
CPU frequency |
Quad Core 1.4GHz |
WEEE tax |
Yes |
Packing quantity |
1.00 |
Volume (m3) |
0.01 |
Tare weight (kg) |
0.32 |
WEE classification |
CL109:6:2017-04-01 |
Gross depth (mm) |
230.00 |
Gross width (mm) |
475.00 |
Gross height (mm) |
60.00 |
Combined (paper) |
113.00 |
Paper/Pasteboard |
260.00 |
Embeeded battery |
No |
Wi-Fi juosta |
No Wi-Fi |
Mesh Support |
No |
Mobile broadband |
No mobile broadband |
MU-MiMO |
No |
Gamintojo prekės serija |
Router Switch |
Bruto svoris |
2.173 |
Tare weight (kg) |
0.373 |
Paper/Pasteboard |
336 |
Plastic (No PET) |
37 |
EEĮ atliekų mokestis |
Yes |
Kiekis pakuotėje |
1.00 |
Tūris (m3) |
0.01 |
Taros svoris (kg) |
0.373 |
EEĮ klasifikacija |
CL109:6:2017-04-01 |
Pakuotės gylis (mm) |
230.00 |
Pakuotės plotis (mm) |
475.00 |
Pakuotės aukštis (mm) |
60.00 |
Popierius/Kartonas |
336 |
Integruota baterija |
No |
Gamintojo prekės serija |
Wired Ethernet Router |
Plastikas (be PET) |
37 |
Procesoriaus dažnis |
1400 |
Įtampa |
(PoE in input Voltage) 20-57 |
Procesoriaus branduoliai |
4 |
Kitos savybės |
New RB1100AHx4 Dude Edition has Annapurna Alpine AL21400 CPU with four Cortex A15 cores clocked at 1.4GHz each, for a maximum throughput of up to 7.5Gbps. The device supports IPsec hardware acceleration and is faster at it than any previous RouterBOARD device (up to 2.2Gbps with AES128). Unit comes with 1U rackmount case, 13x Gigabit Ethernet ports, RS232 serial port and dual redundant power supplies (with -48v DC telecom power and 802.3at/af support). The RB1100AHx4 Dude edition features several high speed storage connectors (two SATA and two M.2) for using a Dude database, proxy cache or any other storage intensive feature. It includes a 60GB M.2 drive already installed. |
Procesoriaus modelis |
AL21400 |
Belaidis ryšys |
No |
PoE in |
802.3af/at |
Sertifikatas |
CE, EAC, ROHS |
Vidinė atmintis |
1000 |
Energijos suvartojimas (maks.) |
33 |
Saugyklos talpa |
128 |
Darbo temperatūra (T-T) |
-40°C to 70°C |
Atminties tipas |
NAND |
