| Form Factor |
Rack 1U |
| TYPE |
Aruba Instant On 1830 Series |
| Standard |
IEEE 802.3uIEEE 802.3ab |
| Ethernet Technology |
Gigabit Ethernet |
| Uplink Port Type |
SFP |
| Number of Network Ports |
12 |
| Interface |
24x RJ-45 autosensing 10/100/1000 ports2x SFP 1GbE ports |
| Data Transfer Rate |
Throughput: 38.68 MppsSwitching capacity: 52 Gbps100 Mb Latency: <5.2 uSec1000 Mb Latency: <2.8 uSec |
| Duplex |
Half / Full |
| Layers Supported |
2 |
| MANAGEMENT |
Smart |
| MAC Address Table |
16 K |
| Data Buffer |
1.5 MB |
| Power |
Voltage: 100-127 / 200-240 VAC (50/60 Hz)Current: 0.4 / 0.3 AIdle power: 7.6 / 7.8 WMax power: 19.1 / 19 W |
| WIDTH |
443 mm |
| Depth |
215.9 mm |
| HEIGHT |
43.9 mm |
| Warranty |
Limited lifetime |
| Manufacturer Datasheet |
https://www.hpe.com/psnow/doc/a50004271enw.pdf?jumpid=in_pdp-psnow-qs |
| Manufacturer Logo URL |
https://www.tdbaltic.ee/images/manufacturers/HPE.jpg |
| Product Highlights |
- Managed L2 Web-based management
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 24
- MAC address table: 16000 entries Switching capacity: 52 Gbit/s
- 1U Rack mounting
|
| Switch type |
Managed |
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| Cloud-managed |
Yes |
| Basic Switching RJ-45 Ethernet Ports Quantity |
24 |
| SFP module slots quantity |
2 |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Port mirroring |
Yes |
| Flow control support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Spanning tree protocol |
Yes |
| VLAN Support |
Yes |
| MAC Address Table |
16000 entries |
| Jumbo Frames support |
Yes |
| Jumbo Frames |
9216 |
| DHCP Features |
DHCP client |
| IGMP snooping |
Yes |
| SSH/SSL support |
Yes |
| Rack Mounting |
Yes |
| Built-in Processor |
Yes |
| Processor Frequency |
800 MHz |
| INTERNAL MEMORY |
512 MB |
| Flash Memory |
256 MB |
| Power Supply Included |
Yes |
| Operating Temperature (T-T) |
0 - 40 °C |
| Storage Temperature (T-T) |
-40 - 70 °C |
| Operating Relative Humidity (H-H) |
15 - 95% |
| Storage Relative Humidity (H-H) |
15 - 95% |
| WIDTH |
215.9 mm |
| Depth |
443 mm |
| Weight |
2.49 kg |
| Warranty Terms |
12 months |
| Product condition |
Original |
| Manufacturer Datasheet |
https://www.tdbaltic.ee/leaflets/HPE/JL812A%23ABBLTSTOCK.pdf |
