Aprašymas

"ALLNET EC25. Device type: Cellular network modem, Product colour: Green. Supported network protocols: TCP/UDP/PPP/FTP/HTTP/SMTP*/MMS*/FTP/ SMTP*/NTP/PING/DTMF/FILE/CMUX/QMI. Data network: LTE, 2G standards: Edge, GPRS, 3G standards: CDMA, DC-HSPA+, TD-SCDMA, UMTS. Certification: CCC/CE/NAL/TA/FCC/PTCRB/AT&T/ Verizon/KC/SKT /RCM/JATE/TELEC. Windows operating systems supported: Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP, Mobile operating systems supported: Android"\n"Quectel EC25 Mini PCIe is a series of LTE category 4 module adopting standard PCI Express® Mini Card form factor (Mini PCIe). It is optimized specially for M2M and IoT applications, and delivers 150 Mbps downlink and 50 Mbps uplink data rates.

EC25 series Mini PCIe contains 12 variants: EC25-E Mini PCIe, EC25-EU Mini PCIe, EC25-EUX Mini PCIe, EC25-J Mini PCIe, EC25-A Mini PCIe, EC25-V Mini PCIe, EC25-AF Mini PCIe, EC25-AFX Mini PCIe, EC25-AFXD Mini PCIe(Data-only), EC25-MX Mini PCIe, EC25-AU Mini PCIe and EC25-AUX Mini PCIe. This makes it backward-compatible with existing EDGE and GSM/GPRS networks, ensuring that it can be connected even in remote areas devoid of 4G or 3G coverage.

EC25 series Mini PCIe supports Qualcomm IZat location technology Gen8C Lite (GPS, GLONASS, BeiDou/Compass, Galileo and QZSS). The integrated GNSS greatly simplifies product design, and provides quicker, more accurate and more dependable positioning.

A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB serial drivers for Windows 7/8/8.1/10, Linux, Android) extend the applicability of the module to a wide range of M2M applications such as industrial router, industrial PDA, rugged tablet PC, video surveillance and digital signage."
