| Form Factor |
Rack 1U |
| TYPE |
Aruba Instant On 1430 Series |
| Standard |
IEEE 802.3iIEEE 802.3uIEEE 802.3zIEEE 802.3abIEEE 802.3afIEEE 802.1atIEEE 802.1xIEEE 802.3azRFC 2474 |
| Ethernet Technology |
Gigabit Ethernet |
| Number of Network Ports |
8 |
| Interface |
8x RJ-45 autosensing 10/100/1000 Class 4 PoE ports |
| Data Transfer Rate |
Throughput: up to 11.9 MppsSwitching capacity 16 GbpsAverage latency: 100 Mbps: 2.7 μSec, 1000 Mbps: 1.8 μSec |
| Duplex |
Half / Full |
| Layers Supported |
2 |
| MAC Address Table |
8 K |
| Data Buffer |
2 MB |
| Power |
Voltage: 100-240 VAC (50/60 Hz)Current: 2A (54VDC - 1.58A)Idle power: 4.7 WMax power: 90 W |
| Pover over Ethernet Budget |
64 W |
| WIDTH |
177 mm |
| Depth |
150 mm |
| HEIGHT |
37 mm |
| Manufacturer Datasheet |
https://www.hpe.com/psnow/doc/a00123902enw |
| Form Factor |
Rack |
| Uplink Port Type |
No |
| MANAGEMENT |
Unmanaged |
| Manufacturer Logo URL |
https://www.tdbaltic.ee/images/manufacturers/HPE.jpg |
| Product Highlights |
- Unmanaged L2
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 8
- 10BASE-T, 100BASE-TX, 1000BASE-T
- MAC address table: 8192 entries Switching capacity: 16 Gbit/s
|
| Switch type |
Unmanaged |
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Yes |
| Basic Switching RJ-45 Ethernet Ports Quantity |
8 |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Flow control support |
Yes |
| Ethernet LAN Data Rates |
10,100,1000 Mbit/s |
| MAC Address Table |
8192 entries |
| Jumbo Frames support |
Yes |
| Jumbo Frames |
9216 |
| Rack Mounting |
No |
| Product colour |
White |
| Power Supply Included |
Yes |
| Operating Temperature (T-T) |
0 - 40 °C |
| Storage Temperature (T-T) |
-40 - 70 °C |
| Operating Relative Humidity (H-H) |
15 - 95% |
| Storage Relative Humidity (H-H) |
15 - 90% |
| WIDTH |
150 mm |
| Depth |
177 mm |
| Weight |
770 g |
| Warranty Terms |
12 months |
| Product condition |
Original |
| Manufacturer Datasheet |
https://www.tdbaltic.ee/leaflets/HPE/R8R46A%23ABBLTSTOCK.pdf |
