COUGAR ATLAS 650 PSU, 80 plus Bronze, 650W (ATX 3.1)
Prekė gali skirtis nuo pavaizduotos paveikslėlyje, taip pat paveikslėlyje gali būti dalių, kurių nėra prekės komplektacijoje.
Prekės kodas: #1762392
Garantija: 60 mėn.
Aprašymas
COUGAR ATLAS 650 PSU, 80 plus Bronze, 650W (ATX 3.1)
-
Informacija apie prekę
-
Papildoma informacija
| Gamintojas |
COUGAR GAMING |
| Maitinimo bloko galingumas (W) |
600 W - 700 W |
| Efektyvumo sertifikatas |
80 Plus Bronze |
| Spalva |
Juoda |
| Power Device Type |
Power Supply |
| Power Device Location |
Internal |
| Input Voltage |
AC 100-240 V |
| Input Frequency |
50/60 Hz |
| Rated Input Current |
10 A |
| Input Power Connectors Quantity |
1 |
| Input Power Connectors Type |
IEC-320 C14 |
| Maximum Output Power |
650 W |
| Circuit Protection |
Over Voltage Undervoltage Over Temperature Over Current Short Circuit Protection Over Power |
| Modular Power Supply |
No |
| Power Adapter and Power Supply Features |
Active PFC |
| Built-in Devices |
Power Button |
| 80 Plus Certification |
80 Plus Bronze |
| Efficiency |
87% |
| +3.3V |
20 A |
| +5V |
20 A |
| +12V |
54.1 A (649.2 W) |
| -12V |
0.3 A (3.6 W) |
| +5VSB |
3 A (15 W) |
| 24-pin Main Connector |
1 |
| 4/8-pin +12V Power Connector |
2 |
| 4-pin Peripheral Power Connector |
2 |
| S-ATA Connector |
6 |
| 6/8-pin PCI Express Connector |
2 |
| 16-pin PCI Express 5.0 (12VHPWR) Connector |
1 |
| External Color |
Juoda |
| Depth (mm) |
140 mm |
| Height (mm) |
86 mm |
| Width (mm) |
150 mm |
| Nominal Weight |
1.8 kg |
| Warranty Products returnable |
Yes |
| Warranty Term (month) |
60 mėn. |
| Warranty validation Criteria |
Serial Number |
| Pack Length (mm) |
187 mm |
| Pack Width (mm) |
158 mm |
| Pack Height (mm) |
165 mm |
| Pieces in pack |
1 |
| Box Length (mm) |
580 mm |
| Box Width (mm) |
495 mm |
| Box Height (mm) |
185 mm |
| Packs in Box |
9 |
| Package Type |
Retail |
| EAN Code |
4711649770181 |
