CHIEFTEC ECO Series 700W ATX-12V V.2.3
Prekė gali skirtis nuo pavaizduotos paveikslėlyje, taip pat paveikslėlyje gali būti dalių, kurių nėra prekės komplektacijoje.
Prekės kodas: #24499
Garantija: 24 mėn.
Aprašymas
The name ECO stands for maximum efficiency, ecological values and an era of power supplies. Compatible with all current standards and with a fixed voltage of 230V being the European standard, the ECO series is a reliable and efficient companion for modern IT structures which thereby also fulfills all ENERGY STAR 5.0 requirements.
-
Informacija apie prekę
-
Papildoma informacija
| Gamintojas |
CHIEFTEC |
| Maitinimo bloko galingumas (W) |
700 W - 800 W |
| ATX12V VERSION |
2.3 |
| DEPTH (cm) |
14 |
| HEIGHT (cm) |
8.7 |
| MOLEX |
2 |
| MOTHERBOARD CONNECTOR |
24pin |
| PCI-E VGA POWER CONNECTORS |
2 x 6pin |
| PFC |
Active |
| POWER SUPPLY OUTPUT |
700W |
| PRODUCT DESCRIPTION |
The name ECO stands for maximum efficiency, ecological values and a new era of power supplies. Compatible with all current standards and certified by TÜV amongst many others and with a fixed voltage of 230V being the European standard, the ECO series is a reliable and efficient companion for modern IT structures which thereby also fulfills all ENERGY STAR 5.0 requirements as stipulated by the EU. |
| PSU FAN SIZE |
12 cm |
| SATA CONNECTORS |
6 |
| WIDTH (cm) |
15 |
| PRODUCT DESCRIPTION |
Chieftec ECO Series GPE-700S - power supply - 700 Watt
|
| Device Type |
Power supply - active Power Factor Correction (PFC) - internal
|
| Specification Compliance |
ATX12V 2.3
|
| Input Voltage |
AC 230 V
|
| Output Voltage |
+3.3, +5, ±12 V
|
| Power Capacity |
700 Watt
|
| Output connectors |
1 x power 24 pin ATX
6 x 15 pin Serial ATA power
2 x 4 PIN internal power
1 x 8 pin PCI Express power with detachable 2 pin section
1 x power 8 pin EPS12V with detachable 4 pin ATX12V section
|
| Cooling System |
120 mm fan
|
| Dimensions (WxDxH) |
15 cm x 14 cm x 8.6 cm
|
| Environmental Standards |
ENERGY STAR
|
| Manufacturer Warranty |
2-year warranty
|
